M480 Series Printers
Laseradd M480 printers adopt a multi-laser and multi-galvanometer same-format forming solution, which can increase the forming efficiency by more than 80%.
It can be used in molds, automobiles, aerospace, nuclear power and military industry, orthopedic medicine and other fields.
- 480×320×300mm buid cylinder size
- Dual IPG lasers & Scanlab galvanometer
- Top powder feeding, two-way variable speed powder spreading
- F theta lenses or dynamic focusing system
- Fresh air protection system
- M480E: Domestic Laser 500W×1
- M480ED: Domestic Laser 500W×2
- M480H: IPG Laser 500W×1
- M480HD: IPG Laser 500W×2
DATA SHEET
| Laseradd DiMetal-M450E SLM 3D Printer | |
| External Dimensions(L*W*H): | 1940 x1110*2075mm |
| Build Cylinder Size(L*W*H): | 450mmx250mmx300mm |
| Scanning Speed: | 15m/s |
| Laser Type: | Dual IPG Laser 500W(Other power lasers are optional) |
| Galvanometer: | F theta lenses or dynamic focusing system |
| Inert Gas Protection: | Argon/Nitrogen |
| Powder Delivery: | Top powder feeding, two-way variable speed powder spreading |
Advantages
-
1
Large-size multi-laser co-radiating surface efficient forming
Multiple lasers and multiple galvanometers work together simultaneously with the same format, which can increase the forming efficiency by more than 80% and achieve efficient forming of large-size parts. Two-way powder coating improves efficiency
-
2
Intelligent operation design
Unattended automatic printing operation, automatic/manual control free switching, self-diagnosis function, safety protection and automatic fault alarm
-
3
Fresh air protection system
The efficient operation of Laseradd fresh air system and double-circulation wind field protection ensure more stable forming and extend the service life of optical parts.
-
4
Full pop-up position system
More convenient and quicker to replace metal powders, and 100% eliminates cross powder contamination when replacing powders
Samples
-
Shoe mold
Build Data
• Kings M480E
• stainless steel
• 20μm and 80μm partitioned mixed layer thickness
one pair for around 18h -
Flowerpot Conformal Cooling Channel
Build Data
• Kings M480H
• CX-Mold Steel
• 60 µm layer thickness -
AlSi10Mg Evtol Protective Cover
Build data：
• Kings M150
• Inconel 718
• 50 µm layer thickness
ACCESSORIES
-
Air filteration system
The air filtration machine captures and filters out airborne particles and fumes generated during the metal 3D printing process. It also filters and supplies gas to the printing chamber, ensuring a stable gas environment, maintaining high printing quality, and protecting optical components.
-
Water Chiller
A water chiller is used to regulate and maintain the temperature of the 3D printer and its components by circulating chilled water. This machine can prevents overheating of the printer and its laser systems, ensuring stable and efficient operation, and extending the lifespan of the equipment.
-
Explosion-proof wet vacuum cleaner
Designed to safely collect potentially explosive or flammable metal powders used in the 3D printing process, so to ensures a clean and safe working environment by preventing dust accumulation and potential ignition sources, reducing the risk of explosions.
-
Drying Oven
To remove moisture from the collected metal powders for future use.
-
Oscillating sieving machine
To sieve metal powders, ensuring that they are of uniform particle size before being used in the 3D printing process. This powder-treating process enhances print quality and consistency by removing oversized or undersized particles from the powder, ensuring smooth and even powder distribution during printing
Consumable
-
1
450*250mm 45# forming plate*4pcs
Aluminum alloy forming plate is optional
-
2
Filter Core
Filter element for air circulation device*4pcs, each one can be used 300 hours
-
3
Soft recoating blade
10 units, suggest to change each month
Material
-
1
316L,Ti6AI4V,AISi10Mg,In 718,CuSn10,CoCr,18Ni300 etc,
The normal particle size of powder is 15~53 microns, Other sizes can be customized
